BEA Flatscan On-Door Safety Sensor

Name: BEA Flatscan On-Door Safety Sensor
SKU: FLATSCAN
Availability: InStock

From : BEA

£718.44 ex vat

The easy-to-install FLATSCAN SW uses time-of-flight laser technology for swing doors to generates 170 measurement points that provide a complete protection for swing doors and their users. A single FLATSCAN SW covers the entire door wing including the hinge area.

Trade Customer?

Looking to order in BULK?

Give us a call today on 01767 315 402 where we can quote you directly.

Colour

Part code: FLATSCAN Category: Safety Sensors Tags: Laser Technology, For Swing Doors

Product Type	Safety Sensor, Swing Door Sensors

Technical

Technology	LASER scanner, time-of-flight measurement
Detection mode	Presence
Max. detection range	4 m (diagonal) with reflectivity of 2% (i.e. : at W = 1.5m -> max. H = 3.7 m)
Opening angle	Door wing safety: 90° / Pinch zone safety: 16°
Angular resolution	Door wing safety: 1.3°/ Pinch zone safety: 0.2°
Typ. min. object size	Door wing safety: 10 cm @ 4m (in proportion to object distance, DIP 2 = ON) Pinch zone safety: 2 cm @ 4m (in proportion to object distance, DIP 2 = ON
Testbody	700 mm × 300 mm × 200 mm (testbody CA according to EN 16005 & DIN 18650)
Emission characteristics	IR LASER: Wavelength 905 nm; max. output pulse power 25 W; Class 1
Supply voltage	12 – 24 V DC ± 15 %
Power consumption	≤ 2 W
Response time	Door wing safety: max. 50 ms / Pinch zone safety: max. 90 ms
Output Max. switching voltage Max. switching current	2 electronic relays (galvanic isolation – polarity free) 42V AC/DC 100 mA
LED-signals	1 bi-coloured LED: detection/output status
Dimensions	142 mm (L) × 85 mm (H) × 33 mm (D) ( mounting bracket + 7 mm )
Material – Colour	PC/ASA – Black – Aluminium – White
Tilt angles	+2° à +10° (without mounting bracket)
Protection degree	IP54 (EN 60529)
Temperature range	-30°C to +60°C if powered
Humidity	0-95 % non-condensing
Vibrations	< 2 G
Min. door wing speed	2°/sec
Norm conformity	EN 12978; EN ISO 13849-1 Pl “d”/ CAT2; IEC 60825-1; EN 60950-1; EN 61000-6-2; EN 61000-6-3; EN 62061 SIL 2; DIN 18650-1 Chapter 5.7.4 (testbody CA); EN 16005 Chapter 4.6.8 (testbody CA)
